Washing Tester

Payment Terms: T/T,L/C,WU;negotiation
Place of Origin: Guangdong, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: TSA008
Production Capacity: 200 set/ month
Delivery Date: 30 workdays
Means of Transport: negotiation
Packing: wooden package

Washing Fastness Tester
Wash pot volume: 550ml for ISO, 1200ml for AATCC
Time accuracy: +-5s

Specification
    Washing Fastness Tester is used to determine color fastness to washing or dry cleaning of fabrics consisting of cotton, wool, silk, ramie, chemical fiber, etc. And to examine the dye washing color fastness capability for dyeing industries, textiles inspection departments and research departments, etc.
Standards: M&S C4,C4A,5,37,C49,P3B ,ISO 105  IWSTM 7,115,177,193,199,240,241,AATCC61 2,3,28,61,62,86,132  BS 1006,JIS L0884,GB/T3921,GB/T5711

KEY SPECIFICATION
 Wash pot volume 550mL (For ISO)/1200ml(For AATCC)
 Number of wash pot 12 (For ISO)/8(For AATCC)
 Rotating speed 40±2r/min
 Max test time 0~999min
 Time accuracy ±5s
 Range of temperature room temperature~99.9
 Temperature accuracy ±1
 Power of heater 4.5kW
 Power of motor 180W
 Power supply AC380V 50Hz 10A(3 phases)
 Instrument dimension 760×480×1100mm( L×W×H)
 Weight  120g
FEATURES
Single working chamber, the temperature, working time, rotation state and drainage  of both chambers are controlled independent;
  • Chamber temperature and heating time are controlled by MCU with PID function, more excellent stability and avoid over-heating;
  • Equipped with SIEMENSTM solid-state relay to control heater, no mechanical touch point, keep constant temperature, low noise, and more endurable;
  • Digital timer with audible warning after cycle time is over;
  • Fitted with over temperature protection device to shut down the unit in case of overheating;
  • Chamber temperature and cycle time pre-settable and duly displayed on the LED panel;
  • Stainless steel construction of water bath chamber, test chamber and washing pots;
  • Equipped with water level detection and protection system for two working chamber to avoid damage for low water level.
Welcome to visit www.tstchina.cn. any help, pls feel free to contact me, Ms.Violet Chen. my phone no is 86+13850793790. tks
